UHF RFID Reader

UHF RFID Android 10.0 Handheld Reader

UHF RFID Android 10.0 Handheld Reader
UHF RFID Android 10.0 Handheld Reader
UHF RFID Android 10.0 Handheld Reader
UHF RFID Android 10.0 Handheld Reader
UHF RFID Android 10.0 Handheld Reader

Description

Reviews

Product Paramenters

Specification

SPECIFICATIONS
PHYSICAL CHARACTERISTICS
Dimension 166mm(H)x79mm(W)x31mm(D)±2 mm
Weight Net Weight :600g (including battery&wrist strap)
Display Gorilla Glass 3 9H 5.5 in. TFT-LCD(720x1440)touch screen with backlight
Backlight LED backlight
Expansions 1 PSAM, 1 SIM, 1 TF
Battery Rechargeable li-ion polymer, 3.8V, 9000mAh
PERFORMANCE CHARACTERSTICS
CPU Cortex A73 2.0GHz octa-core
Operating System Android 10.0
Storage 2GB RAM/16GB ROM or 4GB RAM/64GB ROM, MicroSD(max 256GB expansion)
USER ENVIRONMENT
Operating Temp. -20℃ to 50℃
Storage Temp. -20℃ to 70℃
Humidity 5%RH to 95%RH(non-condensing)
Drop Specifications 5ft./1.5 m drop to concrete across the operating temperature range
Sealing IP65, IEC compliance
ESD ±15kv air discharge, ±8kv direct discharge
DEVELOPMENT ENVIRONMENT
SDK Handheld-Wireless Software Development Kit
Language Java
Environment Android Studio or Eclipse
DATA COMMUNICATION
WWAN TDD-LTE Band 38, 39, 40, 41; FDD-LTE Band 1, 2, 3, 4, 7, 17, 20; WCDMA(850/1900/2100MHz); GSM/GPRS/Edge (850/900/1800/1900MHz);
WLAN 2.4GHz/5.0GHz Dual Frequency, IEEE 802.11 a/b/g/n/ac
WPAN Bluetooth Class v2.1+EDR, Bluetooth v3.0+HS, Bluetooth v4.2
GPS GPS(embedded A-GPS), accuracy of 5 m
DATA CAPTUER
BARCODE READER(OPTIONAL)
2D barcode 2D CMOS Imager Zebra SE4710/Mindeo ME5600
Symbologies PDF417, MicroPDF417, Composite, RSS, TLC-39, Datamatrix, QR code, Micro QR code, Aztec, MaxiCode, Postal Codes, US PostNet, US Planet, UK Postal, Australian Postal, Japan Postal, Dutch Postal. etc.
COLOR CAMERA
Resolution Rear 13 megapixel, front 5.0 megapixel
Lens Auto-focus with LED flash
RFID READER(OPTIONAL)
RFID NFC Frequency 13.56MHz
Protocol ISO 14443A&15693, NFC-IP1, NFC-IP2
R/W Range 2cm to 5cm
RFID UHF Frequency 865~868MHz or 920~925MHz
Protocol EPC C1 GEN2/ISO 18000-6C
Antenna Gain Circular antenna(4dBi)
R/W Range 20 m(tags and environment dependent)
PSAM SECURITY(OPTIONAL)
Protocol ISO 7816
Baudrate 9600, 19200, 38400,43000, 56000, 57600, 115200
Slot 2 slots(maximum)

Use Scenarios

Company Profile

Our Service

Factory & Quality:
We have our own factory and have professional and efficient production lines. And production, assembly, testing, and packaging are completed in their own factory. Every product undergoes rigorous testing and quality control procedures to ensure quality.

OEM & ODM Service:
OEM and ODM orders are accepted, and we can provide customized service to you.

Payment:
We accept PayPal, West Union, TT, etc. All major credit cards are accepted through the secure payment processor ESCROW.

Warranty:
1. We provide 12 month warranty. If the item is defective, please notify us within 3 days of delivery.
2. All items must be returned in their original condition and do not affect the secondary sales, in order to qualify for a refund or exchange of goods.
3. We have a professional after-sales team, that gives you a detailed solution and satisfactory service.

FAQ

1. Q: Are you a factory or trading company?
A: We are an 8 years experience manufacturer, and we will give you a factory price, and support OEM and ODM service.

2. Q: Where is your factory located? How can I visit there?
A: Our factory is located in Shenzhen City, Guangdong Province, China. Welcome to visit us!

3. Q: What is your MOQ?
A: Any quantity is acceptable for your order. And the price is negotiable for large quantities.

4. Q: When will you make the delivery?
A: We can make the delivery within 3-7 working days according to the size of your order.

5. Q: I received products that are different from the pictures, how can I do it?
A: Color differences exist due to lighting and the use of different monitors. We will send the samples to you for confirmation before mass production. If you are not satisfied with it, please contact me or our salesperson for a solution.

6. Q: I received the item in broken, what should I do?
A: Every item before shipping is well inspected. Though they are well packed, sometimes damage can`t be avoided because of the rough handling during shipping. In this case, please contact me and send the pictures to me, let me know the quantity which is broken, and we will resend them to you with the next order.

7. Q: What is your after-sale service?
A: We offer a 100% guarantee on our product and agree 1:1 to replace any defective products.
